3-1/2 mm Dia. × 6 mm Shank × 14 mm DOC × 104 mm OAL, Carbide, Cr, 2 Flute, Square, Solid End Mill
SQ End Mill; 3.5 mm Dia. × 14 mm LOC × 6 mm Shank Dia. × 104 mm OAL ; 4 mm RE ; 2 FL ; Carbide ; CrN ; Series 3742
| Cutting Diameter (DC) | 3.5 mm | Shank Type | Round |
| Connection Diameter Machine Side (DCONMS) | 6 mm | End Shape | Square |
| Depth of Cut Maximum (APMX) | 14 mm | Corner Radius (RE) | 4 mm |
| Overall Length (OAL) | 104 mm | Tool Type | High Performance |
| Cutting Edge Material | Carbide | Style | Square |
| Coating | CrN | Measurement Type | Metric |
| Flute Count (NOF) | 2 | Series/List # | 3742 |
Product Features
| Remarks | •Solid Carbide 2-Flute Square End Single End Mills •Used for general purpose milling in most materials of medium hardness such as steel, brass, iron and non-ferrous materials •Made from premium submicron grain carbide | Country of Origin | Japan |
Shipping Info
Package Length
2.65000
Package Width
.60000
Package Weight
0.04
