3500XL FC20 S .5000 RH SE
SQ End Mill; 12.7 mm Dia. × 50.8 mm LOC × 12.7 mm Shank Dia. × 101.6 mm OAL ; 4 FL ; 20 mm LBS ; Carbide ; FC20 ; Series 3500
| Cutting Diameter (DC) | 12.7 mm | Shank Type | Round |
| Connection Diameter Machine Side (DCONMS) | 12.7 mm | End Shape | Corner Radius |
| Depth of Cut Maximum (APMX) | 50.8 mm | Usable Length (LU) | 20 mm |
| Overall Length (OAL) | 101.6 mm | Tool Type | Single-End |
| Cutting Edge Material | Carbide | Length Group | Extra Long |
| Coating | FC20 | Coolant Supply Property (CSP) | External |
| Flute Count (NOF) | 4 | Decimal Equivalent | 0.1575″ |
| Flute Helix Angle (FHA) | Variable | Series/List # | 3500 |
Product Features
| Country of Origin | USA |
Shipping Info
Package Weight
0.346
