HCM D.62-B-L6.7-C1.0 *
Indexable End Mill; 5/8″ Dia. × 0.42″ Max Depth × 1″ Shank Dia. × 6.7″ OAL × 2.4″ LU ; 2 FL ; Round Shank
| Cutting Diameter (DC/DCX) | 5/8″ | Tool Type | Ball nose endmills |
| Cutting Diameter (DC) | 5/8″ | Usable Length (LU) | 2.4″ |
| Cutting Item Count (CICT) | 1 | Flute Count (NOF) | 2 |
| Depth of Cut Maximum (APMX) | 0.42″ | Torque (TQ) | 69 lbfxin |
| Overall Length (OAL) | 6.7″ | Corner Radius (RE) | 0.313″ |
| Shank Type | Round | Body Half Taper Angle (BHTA) | 5 Degrees |
| Application | | Countersinking | Drill Mill | Profiling | Shouldering | Slanted Shoulder & Chamfer | Slotting | | Front Type | B |
| Connection Diameter Machine Side (DCONMS) | 1″ | Cutting Direction (HAND) | Right Hand |
| Master Insert Identification (MIID) | HBR D.62 | Measurement Type | Inch |
| Weight of Item (WT) | 1.2 Lbs | Body Material | Steel |
| Head Length (LH) | 2.4″ | Connection Code Machine Side (CCMS) | Cylindrical |
Product Features
| Family Description | Ball nose multifunction endmills D=.625″ (BALLPLUS). Each tool can carry various milling insert geometries. | Country of Origin | Israel |
| Remarks | The dimensions are for HBR inserts Insert screw tightening torque 65-70 lb fxin For adaptation click on "More Info" |
