SCCD 065-024-080 ACP3 IC608
SC Drill; 0.256″ Dia. × 0.315″ Shank Dia. × 3.11″ OAL × 1.38″ LCF ; AlTiCrSiN
| Drill Bit Size / Cutting Diameter (DC) | 0.256″ | Cutting Edge Material | Carbide |
| Drill Bit Size / Cutting Diameter (DC) - Inch | 0.256″ | Grade | IC608 |
| Coating | AlTiCrSiN | Measurement Type | Inch |
| Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | | Usable Length (LU) | 0.9449″ |
| Application | | Drilling | | Length Chip Flute (LCF) | 1.38″ |
| Connection Diameter Machine Side (DCONMS) | 0.315″ | Overall Length (OAL) | 3.11″ |
| Coolant Supply Property (CSP) | Coolant Thru | Flute Count (NOF) | 3 |
| Point Angle (SIG) | 140 Degrees | Cutting Direction (HAND) | Right Hand |
| Point Length (PL) | 0.0496″ | Body Material | Carbide |
| Number of Teeth | 3 | Connection Code Machine Side (CCMS) | Cylindrical |
| Shank Length (LS) | 1.417″ | Shank Diameter Tolerance (TCDMM) | h6 |
| Shank Type | Round |
Product Features
| Family Description | Three flute solid carbide drills with coolant holes, drilling depth 3xD | Country of Origin | S.Korea |
Shipping Info
Package Weight
0.090
