BBB2008 BX850
BN End Mill; 0.8 mm Dia. × 0.6 mm LOC × 6 mm Shank Dia. × 50 mm OAL ; 2 FL ; PCBN ; Uncoated
| Cutting Diameter (DC) | 0.8 mm | Applicable Material | | Cast Iron | Hard Materials | |
| Connection Diameter Machine Side (DCONMS) | 6 mm | Application | | Profile Milling | |
| Depth of Cut Maximum (APMX) | 0.6 mm | Corner Radius (RE) | 0.4 mm |
| Overall Length (OAL) | 50 mm | Grade | BX850 |
| Cutting Edge Material | PCBN | Body Material | Carbide |
| Coating | Uncoated | Measurement Type | Metric |
| Flute Count (NOF) | 2 |
Product Features
| Family Description | CBN Ball endmills for die engraving | Country of Origin | JAPAN |
Shipping Info
Package Weight
0.042
