19V-1539LRRA60 IN2505
End Mill Head; 1.561″ Dia. × 0.21″ LOC × 0.67″ Shank Dia. ; 10 FL
| Application | | Chamfering | Slanted Shoulder & Chamfer | Slotting | T Slotting | | Connection Diameter Machine Side (DCONMS) | 0.67″ |
| Cutting Diameter (DC) | 1.561″ | Functional Length (LF) | 0.4″ |
| Flute Count (NOF) | 10 | Profile Angle (PRFA) | 60 Degrees |
| Corner Radius (RE) | 0.008″ | Tool Cutting Edge Angle (KAPR) | 30 Degrees |
| Depth of Cut Maximum (APMX) | 0.21″ | Measurement Type | Inch |
| Cutting Width (CW) | 0.376″ | Body Material | Steel |
Product Features
| Family Description | Back-Angle: 15° 30° & 45° Included Angle: 30°, 60° & 90° | Country of Origin | Usa |
Shipping Info
Package Weight
0.000
