VX5F-15R01
Indexable Face Mill; 1-1/2″ Dia. × 1/2″ Shank Dia. × 1.57″ OAL × 0.39″ LOC ; 5 Inserts ; 90 Degrees
| Cutting Diameter (DC/DCX) | 1-1/2″ | Body Material | Steel |
| Cutting Diameter (DC) | 1-1/2″ | Cutting Direction (HAND) | Right Hand |
| Cutting Item Count (CICT) | 5 | Application | | BALANCIN | Facing | Helical Interpolation | Plunging & Recessing | Rampdown | Shouldering | Slotting | |
| Depth of Cut Maximum (APMX) | 0.39″ | Measurement Type | Inch |
| Connection Diameter Machine Side (DCONMS) | 1/2″ | Tool Cutting Edge Angle (KAPR) | 90 Degrees |
| Overall Length (OAL) | 1.57″ |
Product Features
| Family Description | 32-63 Ra surface finishes when engaging the wiper (WEP) Insert corners: .015″ .031″ & .062″ R V-Bottom pocket fosters easy insert indexing & minimizes insert screw stress | Country of Origin | S.Korea |
Shipping Info
Package Weight
1.664
