BT50SRKIN10X100
Shrink Fit Holder ; 10 mm Hole Dia. ; 100 mm OAL ; 24 mm Body Dia. ; Round Shank
| Connection Diameter Workpiece Side (DCONWS) | 10 mm | Shank Type | Round |
| Shank Size (SS) | 50. | Application | | Tapered shape interface | |
| Body Length (LB) | 62 mm | Thread Designation Inside (THID) | M8X1 |
| Body Length_2 (LB_2) | 51 mm | Clamping Length Workpiece Side (LSCWS) | 100 mm |
| Body Diameter (BD) | 24 mm | Measurement Type | Metric |
| Body Diameter_2 (BD_2) | 32 mm | Tool Type | BT |
| Body Taper End Diameter (BTED) | 201.8 mm | Body Material | Steel |
| Overall Length (OAL) | 100 mm |
Product Features
| Family Description | TungShrink thermal shrinking holder for carbide and HSS with BT shank | Country of Origin | INDIA |
| Remarks | Use only inductive heating device for SRKIN holders. |
Shipping Info
Package Weight
8.585
