Square End Mill; 3/4″ Dia. × 2-1/4″ LOC × 3/4″ Shank Dia. × 4-1/2″ OAL ; 4 FL ; HSSCo8 ; Bright ; Series E2F64
| Cutting Diameter (DC) | 3/4″ | End Shape | Square |
| Connection Diameter Machine Side (DCONMS) | 3/4″ | Applicable Material | | Steel | |
| Depth of Cut Maximum (APMX) | 2-1/4″ | Corner Radius (RE) | 0.03″ |
| Overall Length (OAL) | 4-1/2″ | Corner Chamfer Width (CHW) | 0.03″ |
| Cutting Edge Material | HSSCo8 | Decimal Equivalent | 0.75″ |
| Coating | Uncoated | Measurement Type | Inch |
| Flute Count (NOF) | 4 | Series/List # | E2F64 |
| Flute Helix Angle (FHA) | 35 Degrees | Cutting Direction (HAND) | Right Hand |
| Shank Type | Weldon | Center Cutting | Yes |
Product Features
| Country of Origin | S.Korea |
Shipping Info
Package Length
4.75
Package Width
1.25
Package Height
1.25
Package Weight
0
