46C-1825R5RC00 IN2005
SQ End Mill; 0.188″ Dia. × 1/4″ LOC × 0.188″ Shank Dia. × 2″ OAL ; 3 FL ; Carbide ; TiAlN
| Cutting Diameter (DC) | 0.188″ | Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Aluminum / Non-Ferrous Materials | Super-Alloys / Titanium | |
| Connection Diameter Machine Side (DCONMS) | 0.188″ | Application | | Drill Mill | Drilling | Helical Interpolation | Rampdown | Shouldering | Slotting | |
| Depth of Cut Maximum (APMX) | 1/4″ | Corner Chamfer Width (CHW) | 0.01″ |
| Overall Length (OAL) | 2″ | Grade | IN2005 |
| Cutting Edge Material | Carbide | Body Material | Carbide |
| Coating | TiAlN | Decimal Equivalent | 0.188″ |
| Flute Count (NOF) | 3 | Measurement Type | Inch |
| Flute Helix Angle (FHA) | 38 Degrees | Tool Cutting Edge Angle (KAPR) | 90 Degrees |
| End Shape | Chamfer |
Product Features
| Country of Origin | Israel |
Shipping Info
Package Weight
0.033
