46Y175ISR8LM260 IN2006
Thread Mill; M12 × 1-3/4″ ; 3/8″ Shank Dia. × 3″ OAL ; Carbide ; TiAlN ; IN2006
| Thread Size | M12 | Application | | External Thread Milling | Internal Thread Milling | |
| Thread Pitch (TP) | 1-3/4″ | Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | |
| Connection Diameter Machine Side (DCONMS) | 3/8″ | Cutting Edge Material | Carbide |
| Cutting Diameter (DC) | 0.354 | Usable Length (LU) | 1.02″ |
| Overall Length (OAL) | 3″ | Measurement Type | Inch |
| Flute Count (NOF) | 3 | Grade | IN2006 |
| Coating | TiAlN | Body Material | Carbide |
Product Features
| Country of Origin | Israel |
Shipping Info
Package Weight
0.154
