47D-1020S5RQ01 IN05S
SQ End Mill; 1″ Dia. × 2″ LOC × 1″ Shank Dia. × 5″ OAL ; 4 FL
| Cutting Diameter (DC) | 1″ | Usable Length (LU) | 3″ |
| Connection Diameter Machine Side (DCONMS) | 1″ | Applicable Material | | Cast Iron | Non Ferrous Metals | |
| Depth of Cut Maximum (APMX) | 2″ | Application | Finishing | Roughing | Helical Interpolation | Rampdown | Shouldering | Slotting |
| Overall Length (OAL) | 5″ | Grade | IN05S |
| Cutting Edge Material | Carbide | Tool Type | Center Cut |
| Coating | AlTiN | Body Material | Steel |
| Flute Count (NOF) | 4 | Decimal Equivalent | 1″ |
| Flute Helix Angle (FHA) | 39-41 Degrees | Measurement Type | Inch |
| End Shape | Square | Corner Radius (RE) / Chamfer Width (CHW) | 0.010 R |
Product Features
| Family Description | Excellent chatter dampening Used for both roughing and finishing | Country of Origin | S.Korea |
