GIPA 8-35V-1.20 IC1520
Grooving Insert; 0.315″ CW ; IC1520 ; DLC
| Cutting Width (CW) | 0.315″ | Application | | Ext. Turning Aluminum Wheels | Int. Machining Aluminum Wheels | |
| Corner Radius (RE) | 0.0472″ | Applicable Material | | Aluminum / Non-Ferrous Materials | |
| Clearance Angle Major (AN) | 7 Degrees | Measurement Type | Inch |
| Insert Length (INSL) | 1.181″ | Tool Type | Groove Turn AL,HTA Inserts Inserts |
| Coating | DLC | Body Material | Carbide |
| Grade | IC1520 |
Product Features
| Family Description | V-shaped inserts for machining aluminum wheels. | Country of Origin | Israel |
| Remarks | Precision ground and polished rake to avoid built-up edge Toolholder seat needs to be modified according to insert profile to ensure clearance |
Shipping Info
Package Weight
0.039
