47D00612WERQ571 IN2005
SQ End Mill; 0.236″ Dia. × 0.472″ LOC × 0.236″ Shank Dia. × 2.244″ OAL ; 4 FL ; TiAlN
| Cutting Diameter (DC) | 0.236″ | Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Non Ferrous Metals | Hi Temp Alloys | |
| Connection Diameter Machine Side (DCONMS) | 0.236″ | Application | Helical Interpolation | Rampdown | Shouldering | Slotting |
| Depth of Cut Maximum (APMX) | 0.472″ | Ramping Angle Maximum (RMPX) | 5 Degrees |
| Overall Length (OAL) | 2.244″ | Grade | IN2005 |
| Cutting Edge Material | Carbide | Tool Type | Center Cut |
| Coating | TiAlN | Body Material | Steel |
| Flute Count (NOF) | 4 | Decimal Equivalent | 0.236″ |
| Flute Helix Angle (FHA) | 35-37 Degrees | Measurement Type | Inch |
| End Shape | Square |
Product Features
| Country of Origin | S.Korea |
