HM90 F90AP D2.00-4-.75AMT
Indexable Face Mill; 2″ Dia. × 3/4″ Shank Dia. × 1.166″ OAL × 0.39″ LOC ; 4 Inserts ; 90 Degrees
| Cutting Diameter (DC/DCX) | 2″ | Master Insert Identification (MIID) | HM90 APCT 100302R-PD |
| Cutting Diameter (DC) | 2″ | Coolant Supply Property (CSP) | Coolant Thru |
| Cutting Diameter Maximum (DCX) | 2″ | Body Material | Steel |
| Cutting Item Count (CICT) | 4 | Cutting Direction (HAND) | Right Hand |
| Depth of Cut Maximum (APMX) | 0.39″ | Application | | Counter Boring | Facing | Rampdown | Shouldering | Slotting | |
| Connection Diameter Machine Side (DCONMS) | 3/4″ | Measurement Type | Inch |
| Overall Length (OAL) | 1.18″ | Tool Cutting Edge Angle (KAPR) | 90 Degrees |
| Hub Diameter (DHUB) | 1.65″ | Tool Type | 90° Facemills |
| Arbor Style | A |
Product Features
| Family Description | 90° Light Weight Face Cutters Carrying HM90 AP...T 1003 inserts | Country of Origin | Israel |
| Remarks | 1- with standard square insert 2- with FF (fast feed) insert For adaptation, click on More Info |
Shipping Info
Package Weight
0.686
