E93CN D20-3-MMT12-07
Indexable End Mill; 20 mm Dia. × 5 mm LOC × 19 mm Shank Dia. × 40.36 mm OAL ; 93 Degrees
| Cutting Diameter (DC/DCX) | 20 mm | Functional Length (LF) | 27 mm |
| Cutting Diameter (DC) | 20 mm | Tool Type | Toroidal endmills |
| Cutting Item Count (CICT) | 3 | Connection Thread Nominal Size Machine Side (THSZMS) | T12 |
| Depth of Cut Maximum (APMX) | 5 mm | Drive Size (DRVS) | 16 mm |
| Overall Length (OAL) | 40.36 mm | Coolant Supply Property (CSP) | External |
| Ramping Angle Maximum (RMPX) | 3 Degrees | Tool Cutting Edge Angle (KAPR) | 93 Degrees |
| Application | | Plunging & Recessing | Profiling | Rampdown | Shouldering | Side Plunging | Undercutting | | Cutting Direction (HAND) | Right Hand |
| Connection Diameter Machine Side (DCONMS) | 19 mm | Measurement Type | Metric |
| Master Insert Identification (MIID) | CNHT 070315 | Body Material | Steel |
| Weight of Item (WT) | 0.05 Kg | Connection Code Machine Side (CCMS) | MultiMaster |
Product Features
| Family Description | Endmills with MULTI-MASTER threaded adaptation carrying toroidal inserts (TORMILL). Used for undercutting, for the finish cut of steep or vertical walls, thin walls, long and unsupported workpieces and parts with non-rigid clamping | Country of Origin | Israel |
| Remarks | Do not apply lubricant to the MULTI-MASTER threaded connection For adaptation options, click on More Info |
