46D-1015S1RQ09 IN05S
SQ End Mill; 1″ Dia. × 1-1/2″ LOC × 1″ Shank Dia. × 5″ OAL ; 0.09″ RE ; 3 FL ; Carbide
| Cutting Diameter (DC) | 1″ | Applicable Material | | Cast Iron | Aluminum / Non-Ferrous Materials | |
| Connection Diameter Machine Side (DCONMS) | 1″ | Application | | Helical Interpolation | Rampdown | Shouldering | Slotting | |
| Depth of Cut Maximum (APMX) | 1-1/2″ | Corner Radius (RE) | 0.09″ |
| Overall Length (OAL) | 5″ | Grade | IN05S |
| Cutting Edge Material | Carbide | Tool Type | Center Cut |
| Flute Count (NOF) | 3 | Body Material | Carbide |
| Flute Helix Angle (FHA) | 39-41 Degrees | Decimal Equivalent | 1″ |
| End Shape | Corner Radius | Measurement Type | Inch |
| Usable Length (LU) | 3″ | Corner Radius (RE) / Chamfer Width (CHW) | 0.090 R |
Product Features
| Country of Origin | Israel |
Shipping Info
Package Weight
1.713
