GFN 3U IC354
Parting Off Insert; 0.118″ CW ; Neutral ; Carbide ; TiCN ; IC354
| Cutting Width (CW) | 0.118″ | Max. Grooving Feed (fg(max)) | 0.0051 ″/rev |
| Cutting Edge Material | Carbide | Min. Grooving Feed (fg(min)) | 0.0016 ″/rev |
| Coating | TiCN | Chip Breaker Type | U |
| Grade | IC354 | Tool Type | Parting & Grooving Inserts |
| Shape | 90° Rectangular | Angle | 12 Degrees |
| Cutting Direction (HAND) | Neutral | Measurement Type | Inch |
| Application | | Ext. Grooving | Int. Grooving | Parting | | Body Material | Carbide |
| Applicable Material | | Steel | Stainless Steel | | Cutting Width Tolerance (+/-) (CWTOL) | 0.00157″ |
Product Features
| Family Description | A chipformer for use at low feeds. Recommended for Cr-Ni alloys and low carbon steel, especially in the bearing industry and on similar, problematic materials. The narrow chipformer design ensures short, deformed chips. | Country of Origin | Israel |
Shipping Info
Package Length
4.00000
Package Width
1.50000
Package Height
.75000
Package Weight
0.007
