DGM4-030 T9125
Parting Off Insert; 0.157″ CW × 0.787″ Length × 0.0118″ Corner Radius ; Neutral ; Carbide ; TiCN+Al2O3+TiN ; T9125
| Cutting Width (CW) | 0.157″ | Applicable Material | Steel | |
| Corner Radius (RE) | 0.0118″ | Cutting Edge Angle Major Left Hand (PSIRL) | 0 Degrees |
| Insert Length (INSL) | 0.787″ | Tool Type | Face Turn-Groove Inserts |
| Cutting Edge Material | Carbide | Angle | 12 Degrees |
| Coating | TiCN+Al2O3+TiN | Measurement Type | Inch |
| Grade | T9125 | Body Material | Carbide |
| Cutting Direction (HAND) | Neutral | Insert Seat Size Code (SSC) | 4 |
| Application | | Inserts | |
Product Features
| Family Description | Double-ended inserts, 1st choice for external grooving & parting, tolerance of insert width +/-0.002 inch | Country of Origin | Japan |
| Remarks | For "Max workpiece diameter", click on "More Info". |
Shipping Info
Package Weight
0.011
Related Documentation
Caution: The tool will interfere with the workpiece when grooving larger diameter than Dmax.
