GRIP 635-080Y IC830
| Cutting Width (CW) | 1/4″ | Shape | 90° Rectangular |
| Corner Radius (RE) | 0.031″ | Cutting Edge Material | Carbide |
| Cutting Depth Maximum (CDX) | 0.195″ | Applicable Material | Steel|Stainless Steel|Hi-Temp Alloys |
| Thread Pitch Maximum (TPX) | 0.344″ | Cutting Direction (HAND) | Right Hand |
| Insert Thickness (S) | 1/8″ | Measurement Type | Inch |
| Insert Length (INSL) | 0.748″ | Threads per Inch (TPI) | 8 |
| Feed | 0.0173 inch/rev | Min. Grooving Feed (fg(min)) | .0055in/rev |
| Coating | AlTiN|TiN | Cutting Edge Length (L) | 0.401″ |
| Grade | IC830 | Height | 0.344″ |
Product Features
| Family Description | Double-ended inserts, for turning & grooving in external, internal and face applications. | Country of Origin | Israel |
Shipping Info
Package Weight
.0170
