GITM 5.00K-2.50 IB10H
| Cutting Width (CW) | 0.197″ | Application | | Ext. Grooving | Ext. Profiling | Face Grooving Along Shaft | Int. Grooving | Int. Profiling | |
| Corner Radius (RE) | 0.098″ | Applicable Material | | Hard Materials | |
| Cutting Depth Maximum (CDX) | 0.195″ | Cutting Direction (HAND) | Right Hand |
| Clearance Angle Major (AN) | 7 Degrees | Cutting Position | External |
| Thread Pitch Maximum (TPX) | 0.344″ | Axial Groove Outside Diameter Minimum (DAXN) | 6.3″ |
| Insert Thickness (S) | 1/8″ | Measurement Type | Inch |
| Insert Length (INSL) | 0.591″ | Tool Type | Groove Turn Ultra hard Inserts |
| Minimum Bore Diameter (DMIN) | 2.756″ | Threads per Inch (TPI) | 8 |
| Feed | 0.0071 inch/rev | Min. Grooving Feed (fg(min)) | .0012in/rev |
| Coating | Uncoated | Body Material | Carbide |
| Grade | IB10H | Cutting Edge Length (L) | 0.401″ |
| Shape | 90° Rectangular | Height | 0.344″ |
| Cutting Edge Material | PCBN |
Product Features
| Family Description | CBN tipped inserts for turning and grooving on hard ferrous materials. Used for finishing hard ferrous materials with 45-65 HRc, dry cutting recommended for interrupted cut. | Country of Origin | Switzerland |
| Remarks | DMIN for internal machining = 2.76″ |
Shipping Info
Package Weight
0.022
