7/16″ Dia-2-11/16″OAL-CBD Tip-Left Spiral SE EM-2 FL
SQ End Mill; 7/16″ Dia. × 1″ LOC × 3/8″ Shank Dia. × 2-11/16″ OAL ; 2 FL ; HSS
| Cutting Diameter (DC) | 7/16″ | Flute Count (NOF) | 2 |
| Connection Diameter Machine Side (DCONMS) | 3/8″ | Applicable Material | | Steel | |
| Depth of Cut Maximum (APMX) | 1″ | Tool Type | Single-End |
| Overall Length (OAL) | 2-11/16″ | Length Group | Left Spiral |
| Cutting Edge Material | HSS | Decimal Equivalent | 0.4375″ |
Product Features
| Remarks | •Carbide Tipped End Mills •For Steel, Hardened Steel, & Tough Steel Alloys 6 Left Spiral Flutes, Multi-Flute •Right Hand Cut •The left spiral flutes maintain a constant pressure on the work piece and better absorb the impact shock on entering steel • For milling all types of steel, including hardened steel and other tough steel alloys | Country of Origin | USA |
Shipping Info
Package Weight
0.438
