SNMD646HY TT8115B
Turning Insert; 60 Triangle × 3/4″ IC × 0.094″ Corner Radius
| Insert Style | SNMD | Number of Cutting Edges | 8 |
| Corner Radius (RE) | 0.094″ | Cutting Direction (HAND) | Neutral |
| Insert Size | 190624 | Quantity | 10 |
| Insert Thickness (S) | 1/4″ | Measurement Type | Inch |
| Inscribed Circle Diameter (IC) | 3/4″ | Shape | 60° Triangle |
| Insert Included Angle (EPSR) | 90 Degrees | Series/List # | ISOI |
| Min D.O.C. | 0.16″ | Body Material | Carbide |
| Depth of Cut Maximum (APMX) | 0.47″ | Cutting Edge Effective Length (LE) | 0.656″ |
| Min. Turning Feed (ft(min)) | 0.02″ | Model No | 8866423 |
| Max. Turning Feed (ft(max)) | 0.043″ |
Product Features
| Country of Origin | S.Korea |
Shipping Info
Package Weight
0.063
