CNMX2.221FGP PV3010
Turning Insert; 60 Triangle × 0.276″ IC × 0.016″ Corner Radius
| Insert Style | TPGH | Max. Turning Feed (ft(max)) | 0.01″ |
| Corner Radius (RE) | 0.016″ | Number of Cutting Edges | 4 |
| Insert Size | 321 | Cutting Direction (HAND) | Neutral |
| Insert Thickness (S) | 1/8″ | Quantity | 10 |
| Inscribed Circle Diameter (IC) | 0.276″ | Measurement Type | Inch |
| Insert Included Angle (EPSR) | 80 Degrees | Shape | 60° Triangle |
| Min D.O.C. | 0.012″ | Series/List # | ISOI |
| Depth of Cut Maximum (APMX) | 0.08″ | Body Material | Carbide |
| Min. Turning Feed (ft(min)) | 0.002″ | Model No | 8866423 |
Product Features
| Country of Origin | S.Korea |
Shipping Info
Package Weight
0.006
