RPGX 45E IS35
Turning Insert; 60 Triangle × 1/2″ IC ; IS35 ; Ceramic
| Applicable Material | | Cast Iron | Super-Alloys / Titanium | | Depth of Cut Maximum (APMX) | 0.177″ |
| Application | | Ext. Round Face & Turn | | Min. Turning Feed (ft(min)) | 0.00393 ″/rev |
| Insert Style | RPGX | Max. Turning Feed (ft(max)) | 0.01771 ″/rev |
| Insert Size | 45E | Clearance Angle Major (AN) | 11 Degrees |
| Insert Thickness (S) | 0.313″ | Number of Cutting Edges | 3 |
| Inscribed Circle Diameter (IC) | 1/2″ | Quantity | 10 |
| Insert Included Angle (EPSR) | 60 Degrees | Measurement Type | Inch |
| Cutting Edge Material | Ceramic | Shape | 60° Triangle |
| Grade | IS35 | Series/List # | ISOI |
| Tool Type | Turn Positive Inserts | Body Material | Carbide |
| Min D.O.C. | 0.02″ | Model No | 8866423 |
Product Features
| Family Description | Positive round ceramic inserts for machining cast iron, hardened steel and heat-resistant alloys | Country of Origin | S.Korea |
| Remarks | Tools can be supplied on request. For dimensions and tolerances, see more info. |
Shipping Info
Package Weight
0.008
