18 mm Dia. × 16 mm Shank × 48 mm DOC × 100 mm OAL, Carbide, Cr, 2 Flute, Square, Solid End Mill
Square End Mill; 18 mm Dia. × 48 mm LOC × 16 mm Shank Dia. × 100 mm OAL ; 2 FL ; Carbide ; CrN ; Series 3742
| Cutting Diameter (DC) | 18 mm | End Shape | Square |
| Connection Diameter Machine Side (DCONMS) | 16 mm | Usable Length (LU) | 50 mm |
| Depth of Cut Maximum (APMX) | 48 mm | Corner Radius (RE) | 1.5 mm |
| Overall Length (OAL) | 100 mm | Tool Type | High Performance |
| Cutting Edge Material | Carbide | Style | Square |
| Coating | CrN | Measurement Type | Metric |
| Flute Count (NOF) | 2 | Series/List # | 3742 |
| Shank Type | Round |
Product Features
| Remarks | •Solid Carbide 2-Flute Ball End Single End Mills •Used for radius and contouring part surfaces •Designed to cut materials ranging from nickel base alloy, stainless, tough alloys, abrasives and non-ferrous | Country of Origin | Japan |
Shipping Info
Package Length
4.65000
Package Width
1.00000
Package Height
.90000
Package Weight
.7050
