| Applicable Material | Steel|Stainless Steel|Hi-Temp Alloys| | Tool Type | Turn Negative Insert |
| Application | Back Boring | Boring | Copying | External Turning | Internal Facing | Min D.O.C. | 0.059″ |
| Insert Style | SNMG | Depth of Cut Maximum (APMX) | 0.157″ |
| Corner Radius (RE) | 0.047″ | Max. Turning Feed (ft(max)) | 0.0157 inch/rev |
| Insert Size | 433 | Clearance Angle Major (AN) | 11 Degrees |
| Insert Thickness (S) | 0.187″ | Number of Cutting Edges | 3 |
| Inscribed Circle Diameter (IC) | 1/2″ | Cutting Direction (HAND) | Right Hand |
| Insert Included Angle (EPSR) | 60 Degrees | Quantity | 10 |
| Cutting Edge Material | Carbide | Measurement Type | Inch |
| Coating | TiCN | Shape | Square |
| Grade | IC3028 | Series/List # | ISOI |
| Fixing Hole Diameter (D1) | 0.1772″ | Model No | 8866423 |
Product Features
| Family Description | Double-sided square inserts, positive rake angle that varies along the edge to negative in order to prevent chipping. Special design reduces cratering. Used for carbon and alloy steel, stainless steel and high temp. alloys. | Country of Origin | Israel |
| Remarks | For dimensions and tolerances, see more info. |
Shipping Info
Package Weight
.0183
