| Applicable Material | | Steel | Stainless Steel | | Depth of Cut Maximum (APMX) | 0.512″ |
| Application | | Ext. Round Face & Turn | | Min. Turning Feed (ft(min)) | 0.02755 ″/rev |
| Insert Style | RCMX | Max. Turning Feed (ft(max)) | 0.07874 ″/rev |
| Insert Size | 320 | Clearance Angle Major (AN) | 7 Degrees |
| Insert Thickness (S) | 3/8″ | Number of Cutting Edges | 3 |
| Inscribed Circle Diameter (IC) | 1.26″ | Chip Breaker Type | NR |
| Insert Included Angle (EPSR) | 60 Degrees | Quantity | 10 |
| Cutting Edge Material | Carbide | Measurement Type | Inch |
| Coating | TiCN+Al2O3+TiN | Shape | Round |
| Grade | IC8250 | Series/List # | ISOI |
| Fixing Hole Diameter (D1) | 0.374″ | Body Material | Carbide |
| Tool Type | Turn Positive Inserts | Model No | 8866423 |
| Min D.O.C. | 0.276″ |
Product Features
| Family Description | Round 7° inserts with a positive flank and strong cutting edge for rough turning. | Country of Origin | Israel |
| Remarks | For tolerances, see more info. |
Shipping Info
Package Length
5.12000
Package Width
2.80000
Package Height
.24000
Package Weight
0.203
