CNMM 643 TUS T9115
Turning Insert; 60 Triangle ; 0.76″ Length × 3/4″ IC × 0.047″ Corner Radius ; T9115 ; Carbide ; TiCN+Al2O3+TiN
| Applicable Material | Steel | | Min D.O.C. | 0.0393″ |
| Application | | Inserts | | Depth of Cut Maximum (APMX) | 0.4724″ |
| Insert Style | CNMM | Min. Turning Feed (ft(min)) | 0.0197 ″/rev |
| Corner Radius (RE) | 0.047″ | Max. Turning Feed (ft(max)) | 0.059 ″/rev |
| Insert Size | 643 | Clearance Angle Major (AN) | 11 Degrees |
| Cutting Edge Length (L) | 0.76″ | Number of Cutting Edges | 3 |
| Insert Thickness (S) | 1/4″ | Cutting Direction (HAND) | Neutral |
| Inscribed Circle Diameter (IC) | 3/4″ | Chip Breaker Type | TUS |
| Insert Included Angle (EPSR) | 60 Degrees | Quantity | 10 |
| Cutting Edge Material | Carbide | Measurement Type | Inch |
| Coating | TiCN+Al2O3+TiN | Shape | 60° Triangle |
| Grade | T9115 | Series/List # | CNMM 643-TUS |
| Fixing Hole Diameter (D1) | 0.312″ | Body Material | Carbide |
| Tool Type | Turn Negative Inserts | Model No | 8866423 |
Product Features
| Family Description | Negative relief ang., M class, 80deg rhombic insert, for heavy cutting | Country of Origin | Japan |
Shipping Info
Package Weight
0.063
