CNMG 544 TH T9135
Turning Insert; 60 Triangle ; 0.634″ Length × 5/8″ IC × 0.063″ Corner Radius ; T9135 ; Carbide ; TiCN+Al2O3+TiN
| Applicable Material | Steel | | Min D.O.C. | 0.1181″ |
| Application | | Inserts | | Depth of Cut Maximum (APMX) | 0.2362″ |
| Insert Style | CNMG | Min. Turning Feed (ft(min)) | 0.0118 ″/rev |
| Corner Radius (RE) | 0.063″ | Max. Turning Feed (ft(max)) | 0.0236 ″/rev |
| Insert Size | 544 | Clearance Angle Major (AN) | 11 Degrees |
| Cutting Edge Length (L) | 0.634″ | Number of Cutting Edges | 3 |
| Insert Thickness (S) | 1/4″ | Cutting Direction (HAND) | Neutral |
| Inscribed Circle Diameter (IC) | 5/8″ | Chip Breaker Type | TH |
| Insert Included Angle (EPSR) | 60 Degrees | Quantity | 10 |
| Cutting Edge Material | Carbide | Measurement Type | Inch |
| Coating | TiCN+Al2O3+TiN | Shape | 60° Triangle |
| Grade | T9135 | Series/List # | CNMG 544-TH |
| Fixing Hole Diameter (D1) | 1/4″ | Body Material | Carbide |
| Tool Type | Turn Negative Inserts | Model No | 8866423 |
Product Features
| Family Description | Negative relief ang., M class, 80deg rhombic insert, for medium to heavy cutting | Country of Origin | Japan |
Shipping Info
Package Weight
0.046
