RCMT 10T3M0-14
Turning Insert; Round x 0.394″ IC × 1/64″ Corner Radius ; IC50M ; Carbide ; Uncoated
| Applicable Material | Steel| | Tool Type | Turn Positive Insert |
| Application | Back Boring | Boring | Copying | External Turning | Internal Facing | Min D.O.C. | 0.059″ |
| Insert Style | RCMT | Depth of Cut Maximum (APMX) | 0.197″ |
| Corner Radius (RE) | 1/64″ | Max. Turning Feed (ft(max)) | 0.0197 inch/rev |
| Insert Size | 10T3M0 | Clearance Angle Major (AN) | 11 Degrees |
| Insert Thickness (S) | 0.156″ | Number of Cutting Edges | 3 |
| Inscribed Circle Diameter (IC) | 0.394″ | Cutting Direction (HAND) | Right Hand |
| Insert Included Angle (EPSR) | 60 Degrees | Quantity | 10 |
| Cutting Edge Material | Carbide | Measurement Type | Inch |
| Coating | Uncoated | Shape | Round |
| Grade | IC50M | Series/List # | ISOI |
| Fixing Hole Diameter (D1) | 0.173″ | Model No | 8866423 |
Product Features
| Family Description | Round 7° positive flank inserts used for medium and finish profiling on a wide range of materials. | Country of Origin | Israel |
| Remarks | For dimensions and tolerances, see more info. |
Shipping Info
Package Weight
0.005
