TNG 432T IS8
Turning Insert; TNG 432T IS8 ; 0.866″ Length ; 1/2″ IC ; 0.031″ Corner Radius ; Ceramic ; Uncoated
| Applicable Material | Cast Iron| | Tool Type | Turn Ultra Hard Insert |
| Application | Back Boring | Boring | Copying | External Turning | Internal Facing | Min D.O.C. | 0.004″ |
| Insert Style | TNG | Depth of Cut Maximum (APMX) | 0.197″ |
| Corner Radius (RE) | 0.031″ | Max. Turning Feed (ft(max)) | 0.0197 inch/rev |
| Insert Size | 432 | Clearance Angle Major (AN) | 11 Degrees |
| Cutting Edge Length (L) | 0.866″ | Number of Cutting Edges | 3 |
| Insert Thickness (S) | 0.187″ | Cutting Direction (HAND) | Right Hand |
| Inscribed Circle Diameter (IC) | 1/2″ | Quantity | 10 |
| Insert Included Angle (EPSR) | 60 Degrees | Measurement Type | Inch |
| Cutting Edge Material | Ceramic | Shape | 60° Triangle |
| Coating | Uncoated | Series/List # | ISOI |
| Grade | IS8 | Model No | 8866423 |
| Fixing Hole Diameter (D1) | 0.1772″ |
Product Features
| Family Description | Triangular double-sided ceramic inserts with a T-land. Used for machining cast iron, hardened steel and nickel based alloys. | Country of Origin | S.Korea |
| Remarks | For dimensions and tolerances, see more info. |
Shipping Info
Package Weight
0.014
