SNGA 432T IS8
| Applicable Material | Cast Iron| | Tool Type | Turn Ultra Hard Insert |
| Application | Back Boring | Boring | Copying | External Turning | Internal Facing | Min D.O.C. | 0.004″ |
| Insert Style | SNGA | Depth of Cut Maximum (APMX) | 0.138″ |
| Corner Radius (RE) | 0.031″ | Max. Turning Feed (ft(max)) | 0.0118 inch/rev |
| Insert Size | 432 | Clearance Angle Major (AN) | 11 Degrees |
| Insert Thickness (S) | 0.187″ | Number of Cutting Edges | 3 |
| Inscribed Circle Diameter (IC) | 1/2″ | Cutting Direction (HAND) | Right Hand |
| Insert Included Angle (EPSR) | 60 Degrees | Quantity | 10 |
| Cutting Edge Material | Ceramic | Measurement Type | Inch |
| Coating | Uncoated | Shape | Square |
| Grade | IS8 | Series/List # | ISOI |
| Fixing Hole Diameter (D1) | 0.1772″ | Model No | 8866423 |
Product Features
| Family Description | Square double-sided ceramic inserts with a flat rake for machining cast iron and hardened steel. | Country of Origin | Israel |
| Remarks | For dimensions and tolerances, see more info. |
Shipping Info
Package Weight
0.016
