CNG 433E IS9
Turning Insert; CNG 433E IS9 ; 0.508″ Length ; 1/2″ IC ; 0.0472″ Corner Radius ; Ceramic ; Uncoated
| Applicable Material | | Hi Temp Alloys | | Min D.O.C. | 0.039″ |
| Application | | Ext. 80° Diamond 95° Approach | | Depth of Cut Maximum (APMX) | 0.197″ |
| Insert Style | CNG | Min. Turning Feed (ft(min)) | 0.0039 ″/rev |
| Corner Radius (RE) | 0.0472″ | Max. Turning Feed (ft(max)) | 0.0197 ″/rev |
| Insert Size | 433 | Clearance Angle Major (AN) | 11 Degrees |
| Cutting Edge Length (L) | 0.508″ | Number of Cutting Edges | 3 |
| Insert Thickness (S) | 0.187″ | Cutting Direction (HAND) | Right Hand |
| Inscribed Circle Diameter (IC) | 1/2″ | Chip Breaker Type | A |
| Insert Included Angle (EPSR) | 60 Degrees | Quantity | 10 |
| Cutting Edge Material | Ceramic | Measurement Type | Inch |
| Coating | Uncoated | Shape | 80° Rhombic |
| Grade | IS9 | Series/List # | ISOI |
| Fixing Hole Diameter (D1) | 0.1772″ | Body Material | Carbide |
| Tool Type | Turn Ultra hard Inserts | Model No | 8866423 |
Product Features
| Family Description | 80° rhombic double-sided ceramic inserts with a T-land. Used for machining cast iron, hardened steel and nickel based alloys. | Country of Origin | S.Korea |
| Remarks | For dimensions and tolerances, see more info. |
Shipping Info
Package Weight
0.011
