| Applicable Material | Steel|Stainless Steel| | Tool Type | Turn Positive Insert |
| Application | Back Boring | Boring | Copying | External Turning | Internal Facing | Min D.O.C. | 0.276″ |
| Insert Style | RCMX | Depth of Cut Maximum (APMX) | 0.512″ |
| Corner Radius (RE) | 1/64″ | Max. Turning Feed (ft(max)) | 0.0787 inch/rev |
| Insert Size | 320900 | Clearance Angle Major (AN) | 11 Degrees |
| Insert Thickness (S) | 3/8″ | Number of Cutting Edges | 3 |
| Inscribed Circle Diameter (IC) | 1.26″ | Cutting Direction (HAND) | Right Hand |
| Insert Included Angle (EPSR) | 60 Degrees | Quantity | 10 |
| Cutting Edge Material | Carbide | Measurement Type | Inch |
| Coating | TiCN|Al2O3|TiN | Shape | Round |
| Grade | IC8250 | Series/List # | ISOI |
| Fixing Hole Diameter (D1) | 0.374″ | Model No | 8866423 |
Product Features
| Family Description | Round 7° inserts with a positive flank and strong cutting edge for rough turning. | Country of Origin | Israel |
| Remarks | For tolerances, see more info. |
Shipping Info
Package Weight
.2090
Related Documentation
