XCGT040104LTA K10
Turning Insert; 60 Triangle × 0.173″ IC × 0.016″ Corner Radius ; K10
| Insert Style | XCGT | Cutting Direction (HAND) | Left Hand |
| Corner Radius (RE) | 0.016″ | Quantity | 10 |
| Insert Size | 040104 | Measurement Type | Inch |
| Inscribed Circle Diameter (IC) | 0.173″ | Shape | 60° Triangle |
| Insert Included Angle (EPSR) | 86 Degrees | Series/List # | ISOI |
| Grade | K10 | Body Material | Steel |
| Clearance Angle Major (AN) | 7 Degrees | Model No | 8866423 |
| Number of Cutting Edges | 2 |
Product Features
| Country of Origin | S.Korea |
Shipping Info
Package Weight
0.003
