CXMG 12T504-F3M IC6025
Turning Insert; 60 Triangle ; 13.83 mm Length × 12.5 mm IC × 0.4 mm Corner Radius ; IC6025 ; Carbide ; TiCN+Al2O3+TiN
| Applicable Material | | Stainless Steel | | Tool Type | Turn Negative Inserts |
| Application | | Ext. 80° Diamond 95° Approach | Int. 80° Diamond 95° Approach | | Min D.O.C. | 0.4 mm |
| Insert Style | CXMG | Depth of Cut Maximum (APMX) | 2 mm |
| Corner Radius (RE) | 0.4 mm | Min. Turning Feed (ft(min)) | 0.05 mm/rev |
| Insert Size | 12T504 | Max. Turning Feed (ft(max)) | 0.25 mm/rev |
| Cutting Edge Length (L) | 13.83 mm | Number of Cutting Edges | 3 |
| Insert Thickness (S) | 5.8 mm | Quantity | 10 |
| Inscribed Circle Diameter (IC) | 12.5 mm | Measurement Type | Metric |
| Insert Included Angle (EPSR) | 60 Degrees | Shape | 60° Triangle |
| Cutting Edge Material | Carbide | Series/List # | ISOI |
| Coating | TiCN+Al2O3+TiN | Body Material | Carbide |
| Grade | IC6025 | Model No | 8866423 |
Product Features
| Family Description | 80° double-sided and double-positive rhombic inserts with a positive rake for finishing on stainless steel and H.T.A. Clamped in a dovetail rigid clamping pocket. Can be regarded as two positive inserts. | Country of Origin | Israel |
| Remarks | For dimensions and tolerances, see more info. |
Shipping Info
Package Weight
0.027
