SNMG433-ZF T9115
Turning Insert; 60 Triangle × 1/2″ IC × 1/64″ Corner Radius ; T9115 ; Carbide ; TiCN|Al2O3|TiN
| Applicable Material | Steel| | Fixing Hole Diameter (D1) | 0.203″ |
| Application | Back Boring | Boring | Copying | External Turning | Internal Facing | Tool Type | Turn Negative Insert |
| Insert Style | SNMG | Max. Turning Feed (ft(max)) | 0.0079 inch/rev |
| Corner Radius (RE) | 1/64″ | Clearance Angle Major (AN) | 11 Degrees |
| Insert Size | 433 | Number of Cutting Edges | 3 |
| Insert Thickness (S) | 0.187″ | Cutting Direction (HAND) | Right Hand |
| Inscribed Circle Diameter (IC) | 1/2″ | Quantity | 10 |
| Insert Included Angle (EPSR) | 60 Degrees | Measurement Type | Inch |
| Cutting Edge Material | Carbide | Shape | 60° Triangle |
| Coating | TiCN|Al2O3|TiN | Series/List # | ISOI |
| Grade | T9115 | Model No | 8866423 |
Product Features
| Family Description | Negative relief ang., M class, square insert, for finishing | Country of Origin | Japan |
Shipping Info
Package Weight
0.022
