BNMX150720L-HF TT8115
Turning Insert; 60 Triangle × 0.59″ IC ; TT8115 ; Carbide ; TiCN+Al2O3+TiN
| Insert Style | BNMX | Min. Turning Feed (ft(min)) | 0.02″ |
| Insert Size | 150720 | Max. Turning Feed (ft(max)) | 0.118″ |
| Insert Thickness (S) | 0.315″ | Number of Cutting Edges | 6 |
| Inscribed Circle Diameter (IC) | 0.59″ | Cutting Direction (HAND) | Left Hand |
| Cutting Edge Material | Carbide | Quantity | 10 |
| Coating | TiCN+Al2O3+TiN | Measurement Type | Inch |
| Grade | TT8115 | Shape | 60° Triangle |
| Fixing Hole Diameter (D1) | 0.244″ | Series/List # | ISOI |
| Min D.O.C. | 0.02″ | Body Material | Steel |
| Depth of Cut Maximum (APMX) | 0.1″ | Model No | 8866423 |
Product Features
| Country of Origin | S.Korea |
Shipping Info
Package Weight
0.045
