| Applicable Material | Steel|Stainless Steel| | Tool Type | Turn Negative Insert |
| Application | Back Boring | Boring | Copying | External Turning | Internal Facing | Min D.O.C. | 0.059″ |
| Insert Style | CNMG | Depth of Cut Maximum (APMX) | 0.157″ |
| Corner Radius (RE) | 0.047″ | Max. Turning Feed (ft(max)) | 0.0157 inch/rev |
| Insert Size | 433 | Clearance Angle Major (AN) | 11 Degrees |
| Cutting Edge Length (L) | 0.508″ | Number of Cutting Edges | 3 |
| Insert Thickness (S) | 0.187″ | Cutting Direction (HAND) | Right Hand |
| Inscribed Circle Diameter (IC) | 1/2″ | Quantity | 10 |
| Insert Included Angle (EPSR) | 60 Degrees | Measurement Type | Inch |
| Cutting Edge Material | Cermet | Shape | 80° Rhombic |
| Coating | Uncoated | Series/List # | ISOI |
| Grade | IC20N | Model No | 8866423 |
| Fixing Hole Diameter (D1) | 0.1772″ |
Product Features
| Family Description | Double-sided 80° rhombic inserts with a positive rake angle and sharp, positive radial edge. Used for machining very ductile materials like aluminum alloys, soft, low carbon steel, stainless steel, and high temperature alloys. | Country of Origin | ISRAEL |
| Remarks | For dimensions and tolerances, see more info. |
Shipping Info
Package Weight
0.012
