CCET32.52L-GF TT9020
Turning Insert; 60 Triangle ; 0.382″ Length × 3/8″ IC × 0.031″ Corner Radius ; TT9020 ; Carbide ; TiCN
| Insert Style | CCET | Depth of Cut Maximum (APMX) | 0.1″ |
| Corner Radius (RE) | 0.031″ | Min. Turning Feed (ft(min)) | 0.003″ |
| Insert Size | 32.52 | Max. Turning Feed (ft(max)) | 0.009″ |
| Cutting Edge Length (L) | 0.382″ | Clearance Angle Major (AN) | 7 Degrees |
| Insert Thickness (S) | 0.156″ | Number of Cutting Edges | 2 |
| Inscribed Circle Diameter (IC) | 3/8″ | Cutting Direction (HAND) | Left Hand |
| Insert Included Angle (EPSR) | 80 Degrees | Quantity | 10 |
| Cutting Edge Material | Carbide | Measurement Type | Inch |
| Coating | TiCN | Shape | 60° Triangle |
| Grade | TT9020 | Series/List # | 32.52-GF |
| Fixing Hole Diameter (D1) | 0.173″ | Body Material | Carbide |
| Min D.O.C. | 0.016″ | Model No | 8866423 |
Product Features
| Country of Origin | S.Korea |
