RCMX120400 TT7005
Turning Insert; 60 Triangle × 0.472″ IC ; TT7005 ; Carbide ; TiCN+Al2O3+TiN
| Insert Style | RCMX | Min. Turning Feed (ft(min)) | 0.012″ |
| Insert Size | 120400 | Max. Turning Feed (ft(max)) | 0.024″ |
| Insert Thickness (S) | 0.187″ | Clearance Angle Major (AN) | 7 Degrees |
| Inscribed Circle Diameter (IC) | 0.472″ | Quantity | 10 |
| Cutting Edge Material | Carbide | Measurement Type | Inch |
| Coating | TiCN+Al2O3+TiN | Shape | 60° Triangle |
| Grade | TT7005 | Series/List # | ISOI |
| Fixing Hole Diameter (D1) | 0.165″ | Body Material | Carbide |
| Min D.O.C. | 0.098″ | Model No | 8866423 |
| Depth of Cut Maximum (APMX) | 0.197″ |
Product Features
| Country of Origin | S.Korea |
Shipping Info
Package Weight
0.016
