STCL1212X18-CHP
Parting Off Holder; 120 mm OAL × 1.2 mm CW Min. × 1.2 mm CW Max. × 9 mm OAH ; Steel
| Shank Height (H) | 12 mm | Cutting Position | External |
| Shank Width (B) | 12 mm | Application | | Ext Threading | External grooving | |
| Body Width (WB) | 0.9 mm | Shank Standard | Square |
| Cutting Width Minimum (CWN) | 1.2 mm | Body Material | Steel |
| Cutting Width Maximum (CWX) | 1.2 mm | Tool Type | Parting & Grooving Tools |
| Overall Length (OAL) | 120 mm | Work Piece Parting Diameter Maximum (CUTDIA) | 15 mm |
| Head Length (LH) | 18.5 mm | Cutting Direction (HAND) | Left Hand |
| Overall Height (OAH) | 9 mm | Measurement Type | Metric |
Product Features
| Family Description | External grooving and threading tools with high pressure coolant channels for swiss lathes. Compatible to the direct internal coolant supply system without the use of external coolant hose. | Country of Origin | Japan |
| Remarks | The right hand insert (TC*18R...) is used for the right hand toolholders (STCR...), and the left hand insert (TC*18L...) is used for the left hand toolholders (STCL...). Torque: Recommended torque (Nm) for clamping. |
Shipping Info
Package Weight
0.915
