| Shank Size (SS) | ER16 | Measurement Type | Inch |
| Body Diameter (BD) | 0.457″ | Body Material | Steel |
| Coolant Supply Property (CSP) | Coolant Thru | Functional Length (LF) | 0.457″ |
| Tool Type | Spring Collets | Overall Length (OAL) | 1.24″ |
Product Features
| Family Description | Shanks that mount MULTI-MASTER solid carbide heads with an ER collet adaptation | Country of Origin | Israel |
| Remarks | Do not apply lubricant to the threaded connection. For adaptation click on More Info. When a rigid ER collet is assembled in an ER holder, the actual protrud ing length of the holder becomes shorter by .0787 for ER20 and by .118 fo r ER25/ER32 |
Shipping Info
Package Weight
0.15
