| Cutting Diameter (DC) | 2.244″ | Shank Length (LS) | 8.54″ |
| Usable Length (LU) | 8.54″ | Overall Length (OAL) | 8.54″ |
| Application | Drilling | Coolant Supply Property (CSP) | Through Hole |
| Connection Diameter Machine Side (DCONMS) | 1-1/2″ | Cutting Diameter Maximum (DCX) | 2.244″ |
| Shank Size (SS) | 1″ | Measurement Type | Inch |
| Tool Type | Indexable Head Drill | Length Group | 2D |
| Protruding Length (LPR) | 8.54″ | Master Insert Identification (MIID) | SOMT 16 |

Product Features
| Family Description | Indexable insert drills, drilling depth 2xD. | Country of Origin | Israel |
| Remarks | Hole diameter can be changed by shifting drill center along lathe X-axis. Hole tolerance: D+.006/-.002 in average conditions. However, it can be higher or lower according to machine and tooling conditions. |
Shipping Info
Package Weight
1.4770
