Q0325130N6R01
Indexable Insert Drill; 1.281″ Dia. × 5.12″ LU × 1-1/4″ Shank Dia. × 9-1/4″ OAL ; 4 ; Steel
| Cutting Diameter (DC) | 1.281″ | Overall Length (OAL) | 9-1/4″ |
| Usable Length (LU) | 5.12″ | Cutting Item Count (CICT) | 2 |
| Application | | Drill Mill | Drilling | | Flange Diameter (DF) | 2.165″ |
| Connection Diameter Machine Side (DCONMS) | 1-1/4″ | Measurement Type | Inch |
| Shank Size (SS) | 1″ | Length Group | 4× |
| Tool Type | Indexable Drill | Effective No. of Teeth | 1 |
| Shank Length (LS) | 2.362″ | Body Material | Steel |
| Functional Length (LF) | 6.89″ | Decimal Equivalent | 1.281″ |
Product Features
| Country of Origin | S.Korea |
Shipping Info
Package Weight
2.756
