MM TS1.00-H187D-06T10 IC328
End Mill Head; 1″ Dia. × 0.7″ LOC × 0.177″ Max Depth × 0.96″ Shank Dia. × 12.09″ OAL ; 6 FL ; T10 ; Carbide ; TiCN ; IC328
| Application | | Internal Groove Milling | Side Slotting | T Slotting | | Overall Length (OAL) | 12.09″ |
| Cutting Diameter (DC) | 1″ | Grade | IC328 |
| Applicable Material | | Steel | Stainless Steel | Hi Temp Alloys | | Coating | TiCN |
| Flute Count (NOF) | 6 | Tool Cutting Edge Angle (KAPR) | 90 Degrees |
| Corner Radius (RE) | 0.015″ | Measurement Type | Inch |
| Connection Thread Nominal Size Machine Side (THSZMS) | T10 | Cutting Edge Material | Carbide |
| Cutting Depth Maximum (CDX) | 0.177″ | Tool Type | Solid "T" slot cutters |
| Depth of Cut Maximum (APMX) | 0.7″ | Body Material | Carbide |
| Cutting Width (CW) | 0.187″ | Corner Radius (RE) / Chamfer Width (CHW) | 0.12″ |
| Connection Diameter Machine Side (DCONMS) | 0.96″ | Connection Code Machine Side (CCMS) | MultiMaster |
Product Features
| Family Description | Interchangeable solid carbide T-Slot milling heads with various corner radii and MULTI-MASTER threaded adaptation. | Country of Origin | Israel |
| Remarks | Inserts in .197″ and wider feature chip splitting edges For tightening torques and clamping instructions, click on "More Info" Do not apply lubricant to the threaded connection. |
Shipping Info
Package Weight
0.079
