MM TS105-N20D-06T04 IC928
End Mill Head; 10.5 mm Dia. × 2 mm Max Depth × 8 mm Shank Dia. × 9.25 mm OAL ; 6 FL ; T04 ; Carbide ; TiAlN ; IC928
| Application | | Internal Groove Milling | Side Slotting | T Slotting | | Overall Length (OAL) | 9.25 mm |
| Cutting Diameter (DC) | 10.5 mm | Grade | IC928 |
| Applicable Material | | Steel | Stainless Steel | Super-Alloys / Titanium | | Coating | TiAlN |
| Flute Count (NOF) | 6 | Tool Cutting Edge Angle (KAPR) | 90 Degrees |
| Corner Radius (RE) | 0.4 mm | Measurement Type | Metric |
| Connection Thread Nominal Size Machine Side (THSZMS) | T04 | Cutting Edge Material | Carbide |
| Cutting Depth Maximum (CDX) | 2 mm | Tool Type | Solid "T" slot cutters |
| Cutting Width (CW) | 2 mm | Body Material | Carbide |
| Connection Diameter Machine Side (DCONMS) | 8 mm | Corner Radius (RE) / Chamfer Width (CHW) | 0.12″ |
| Functional Length (LF) | 15 mm | Connection Code Machine Side (CCMS) | MultiMaster |
Product Features
| Family Description | MULTI-MASTER interchangeable solid carbide T-Slot milling heads. | Country of Origin | Israel |
| Remarks | For tightening torques and clamping instructions, click on "More Info". Do not apply lubricant to the threaded connection. |
Shipping Info
Package Weight
0.042
