MM HCD160-090-2T10 IC908
End Mill Head; 1″ Dia. × 0.587″ LOC × 0.7″ Max Depth × 0.96″ Shank Dia. × 1.098″ OAL ; 2 FL ; T10 ; Carbide ; TiAlN ; IC908
| Cutting Diameter (DC) | 1″ | Overall Length (OAL) | 1.098″ |
| Applicable Material | Steel|Stainless Steel|Cast Iron|Hard Materials|Hi-Temp Alloys | Grade | IC908 |
| Flute Count (NOF) | 2 | Coating | TiAlN |
| Connection Thread Nominal Size Machine Side (THSZMS) | T10 | Measurement Type | Inch |
| Cutting Depth Maximum (CDX) | 0.7″ | Cutting Edge Material | Carbide |
| Cutting Diameter Maximum (DCX) | 0.059″ | End Shape | Chamfer|Countersink |
| Depth of Cut Maximum (APMX) | 0.587″ | Corner Radius (RE) / Chamfer Width (CHW) | 0.12″ |
| Connection Diameter Machine Side (DCONMS) | 0.96″ |
Product Features
| Family Description | Interchangeable 2 flute solid carbide heads for chamfering, countersinking and spot drilling. | Country of Origin | Israel |
| Remarks | For Clamping keys (should be ordered separately), tightening torques and clamping instructions, click on "More Info". Do not apply lubricant to the threaded connection. |
Shipping Info
Package Weight
0.092
