HM90 E90A-D1.50-3-W1.25-C
Indexable End Mill; 1-1/2″ Dia. × 0.394″ LOC × 1-1/4″ Shank Dia. × 4.3″ OAL ; 3 FL ; Weldon Shank ; 90 Degrees
| Cutting Diameter (DC/DCX) | 1-1/2″ | Head Length (LH) | 1.2″ |
| Cutting Diameter (DC) | 1-1/2″ | Functional Length (LF) | 3.159″ |
| Cutting Item Count (CICT) | 3 | Tool Type | 90° Indexable End Mill |
| Depth of Cut Maximum (APMX) | 0.394″ | Flute Count (NOF) | 3 |
| Overall Length (OAL) | 4.3″ | Coolant Supply Property (CSP) | Coolant Thru |
| Shank Type | Weldon | Tool Cutting Edge Angle (KAPR) | 90 Degrees |
| Ramping Angle Maximum (RMPX) | 2.7 Degrees | Cutting Direction (HAND) | Right Hand |
| Application | | Counter Boring | Facing | Helical Interpolation | Rampdown | Shouldering | Slotting | | Measurement Type | Inch |
| Connection Diameter Machine Side (DCONMS) | 1-1/4″ | Body Material | Steel |
| Master Insert Identification (MIID) | APKT 1003PDR-HM | Connection Code Machine Side (CCMS) | Cylindrical |
| Weight of Item (WT) | 1.46 Lbs |
Product Features
| Family Description | Endmills carrying HM90 AP.. 1003... inserts. | Country of Origin | Israel |
| Remarks | For adaptation, click on "More Info" |
